USB-C Power Delivery solutions cuts development time

Escrito por Agencias Externas el 25/08/2020 a las 17:50:43
1018

Overcome the challenges of implementing USB-C Power Delivery (PD) with the MAX77958 USB-C PD controller and the MAX77962 28W buck-boost charger from Maxim Integrated Products, Inc. (NASDAQ: MXIM).  As portable devices add new technologies such as 5G connectivity and 4K video, many are changing from single-cell to two-series (2S) cell architectures. With this change, comes the need for higher power delivery via USB-C PD and higher-power charging (25W or higher). With the MAX77958 USB-C PD controller, designers can now cut development time by three months with an out-of-the-box USB-C PD compliant solution, while also reducing the solution size in half with the MAX77962 buck-boost charger.


MAX77958:  While USB-C PD systems are capable of meeting the demands of next-generation portable consumer, industrial and medical electronics, compliance to these USB-C specifications requires multiple components and custom firmware that can take several months to develop. The MAX77958 standalone USB-C PD controller saves three months of design, development and testing time with an out-of-the-box USB-C PD 3.0 compliant solution with Fast Role Swap and Dual Role Port (DRP) support. The MAX77958 includes features not typically integrated in traditional USB-C controllers, such as BC1.2 detection and integrated D+/D- switch for legacy USB port support. To enable robust designs, the IC features 28V VBUS rating, CC pin short protection, moisture detection and corrosion prevention.


MAX77962:  New USB-C PD systems enable rapid charging of 2S Li+ batteries using an input voltage of 5V to 20V. The MAX77962 integrates high-voltage FETs (30V absolute maximum voltage) capable of delivering 28W of charging power in half the size of other 28W solutions. This buck-boost charger accepts an input voltage range from 3.5V to 23V, supporting USB-C PD as well as legacy USB sources.


The MAX77962 buck-boost charger and MAX77958 USB-C PD controller are suitable for applications such as game players, augmented reality/virtual reality (AR/VR) devices, cameras, wireless speakers, portable printers and handheld computers, as well as industrial equipment and medical devices.


Key Advantages:





  • Faster Development Time: Out-of-the-box USB-C PD compliance cuts development time; MAX77958 PD controller eliminates three months of firmware development with a GUI-driven customization script, BC1.2 support, Fast Role Swap, DRP mode and integrated D+/D- switch
  • Robust Design: MAX77958 USB-C PD controller features a 28V VBUS rating, integrated protection against shorting the USB-C Configuration Channel (CC) pins, moisture detection and corrosion prevention to enable robust designs
  • Smaller Size: MAX77962 buck-boost charger integrates all power FETs to reduce solution size by 50 percent
  • Wide Voltage Range: MAX77962 buck-boost charger offers a wide input voltage range of 3.5V to 23V supporting USB-C PD; Enables 28W rapid charging of 2S Li+ batteries
